Modeling
3D Tekla models of structural steel members and connections, built directly from design drawings — beams, columns, bracing, purlins and miscellaneous steel.
TEKLA STRUCTURES · AISC / MM STANDARDS
12+ years detailing structural steel for fabricators and contractors — modeling, editing, checking and estimation, delivered on schedule, every time.
Full-scope steel detailing in Tekla Structures, built to AISC and MM standards, for fabricators, contractors and EPCs.
3D Tekla models of structural steel members and connections, built directly from design drawings — beams, columns, bracing, purlins and miscellaneous steel.
Revision handling and model updates against RFIs and design changes, with full drawing-set regeneration and clash resolution.
Independent detail checking against AISC 360 and project-specific connection design criteria before drawings go to fabrication.
Material take-offs and tonnage estimates from the 3D model — accurate quantities for bidding and procurement, in MM or imperial units.
Every drawing that leaves our office has been modeled, edited and checked by an experienced Tekla team before it reaches you. We hold our schedules the way a fabricator holds tolerances — because a late drawing costs you shop time, and that's not a cost we're willing to pass on.
A fixed sequence, tracked from kickoff to delivery — so you always know where your job stands.
Design drawings, specs and connection criteria reviewed against project scope.
3D Tekla model built — members, connections, bolts, welds.
Independent detail check against AISC / MM standards and RFIs.
Tonnage and material take-off extracted from the checked model.
Shop & erection drawings issued, on schedule.
Send us your drawings and scope — we'll come back with a schedule and a number.
Anna Nagar, Chennai
Kanyakumari District branch
Tamil Nadu, India
